HP4-417 Control Box
HP4-417 Control Box ONLY.
For use with the 1040 handpiece H.MH-140
Control Box with Front Panel LED
- Dial speed control sets precise speed and can set a maximum speed for operation with foot control
- LED digital speed display
- Select: Forward or Reverse rotation, Dial or Foot speed control, 115 or 230 Volt
- Built in overload protection
- Convenient handpiece holder with four (4) optional locations on control box
- Tray with lip on top of control box to hold small items
Specs: 50/60 Hz, 250 Input Watts, 6˝ wide x 8˝ deep x 4-1/4˝ high, 6´ cord, weighs 5.4 lbs.
$635.71
Out of stock
Want to be notified when this product is back in stock?
HP4-417 Control Box for use with the 1040 handpiece H.MH-140
Two speed settings:
Setting 1 – Full speed range up to 50,000 RPM.
Setting 2 – 500 RPM – 5,000 RPM.
- Maximum Torque – (11.3 oz-in / 8 N-Cm) or 160 Watts Output Power
- Sealed housing eliminates dust, noise, and vibration
- 115 or 230 Volt
- Two Year Warranty
- UKCA and CE marked, double insulated
Specs: 8.6 lbs. kit shipping weight, shipping dimensions: 12˝ x 10-1/4˝ x 5-1/
Control Box with Front Panel LED
- Dial speed control sets precise speed and can set a maximum speed for operation with foot control
- LED digital speed display
- Select: Forward or Reverse rotation, Dial or Foot speed control, 115 or 230 Volt
- Built in overload protection
- Convenient handpiece holder with four (4) optional locations on control box
- Tray with lip on top of control box to hold small items
Specs: 50/60 Hz, 250 Input Watts, 6˝ wide x 8˝ deep x 4-1/4˝ high, 6´ cord, weighs 5.4 lbs.
Variable Speed Foot Control: 3-3/4˝ wide x 6-1/4˝ long x 2-1/2˝ high, weighs 25 oz.
Click here to view info sheet.
Click here to view Foredom micromotor comparison chart
Additional information
| Weight | 9 lbs |
|---|---|
| Dimensions | 12 × 10.5 × 5.5 in |
| Plug Type / Voltage |
