C.EMX-2 Table Top Control, 230 Volt – International

230V table top speed control with solid state electronics and dial for precise speed settings for Series LX and LXH motors. See Product Options for plug options.


SKU C.EMX-2 - C.EMX-21 - C.EMX-22 - C.EMX-26 Category


Use Product Options Menu to Select Power Cord Plug Option: -2 for US Plug (C.EMX-2), -21 for UK Plug (C.EMX-21), -22 for Continental European (C.EMX-22) or -26 for Australian Plug (C.EMX-26).

230 Volt model of Foredom’s table top speed control is constructed of heavy-duty plastic with durable solid state electronics. It has a dial control for precise speed settings, as well as good repeatability of previous settings. C.EMX-2 has special electronics that converts AC current from an electrical outlet to DC current- the type required by the motor. It also has a special plug that fits the motor’s shielded plug.

For use with 230 Volt M.LX, M.LXB, M.LXH and M.LXBH motors. (Series TX motors are ONLY available in 115V).

5″ long, 5-7/8″ wide, 2-3/4″ high, packaged wt-2 lb/1 kg, 3 Amps, 50 Hz

Other choices for speed control include: Foredom’s C.TXR-2 or C.SXR-2 controls.

Replacement Parts: 3 amp Replacement Fuse, CP10513, is located between the cords in the back of the speed control box. This fuse is good for both 115V and 230V models.  The 230V Circuit Board, CP10495-2, can also be replaced. See Related Products below.

Additional information

Weight 2.6 lbs
Dimensions 9 × 7 × 5 in
SKU - Power Plug

C.EMX-2 – North America, C.EMX-21 – United Kingdom, C.EMX-22 – Continental Europe, C.EMX-26 – Australia
